Products Description
Double braided polyester rope is a versatile and high-quality cordage solution widely used in various industries and applications. This type of rope is constructed with a unique double braided structure, which consists of an inner braided core and an outer braided cover. The inner core provides the rope with excellent tensile strength and stability, while the outer cover offers protection against abrasion, UV damage, and environmental elements, ensuring the rope's durability and longevity.
Polyester, the primary material used in this rope, is renowned for its exceptional balance of strength, flexibility, and resistance to water absorption. Unlike some other materials, polyester does not stretch excessively under load, making it highly reliable for tasks that require consistent tension and precise handling. Additionally, its resistance to rot and mildew ensures that the rope remains in excellent condition even when exposed to wet or humid environments.
Color Available
Specification
| Dia | Circ | Weight | 3-Strand | 8-Strand | 12-Strand | ||||||||
| mm | Inch | Inch | KG/M | KG/220M | ISO1140:2012(E) | Acual MBL/KN | Acual MBL/TON | ISO1140:2012(E) | Acual MBL/KN | Acual MBL/TON | ISO1140:2012(E) | Acual MBL/KN | Acual MBL/TON |
| MBL/KN | MBL/KN | MBL/KN | |||||||||||
| 10 | 3/8 | 1-1/4 | 0.08 | 16.94 | 14.40 | 18.00 | 1.84 | - | - | - | - | - | - |
| 12 | 1/2 | 1-1/2 | 0.11 | 24.20 | 20.20 | 25.25 | 2.58 | 20.70 | 25.88 | 2.64 | 22.50 | 28.13 | 2.87 |
| 14 | 9/16 | 1-3/4 | 0.15 | 33.00 | 27.00 | 33.75 | 3.44 | - | - | - | - | - | - |
| 16 | 5/8 | 2 | 0.20 | 43.12 | 36.00 | 45.00 | 4.59 | 36.00 | 45.00 | 4.59 | 38.30 | 47.88 | 4.89 |
| 18 | 3/4 | 2-1/4 | 0.25 | 54.56 | 45.00 | 56.25 | 5.74 | - | - | - | - | - | - |
| 20 | 4/5 | 2-1/2 | 0.31 | 67.32 | 54.00 | 67.50 | 6.89 | 56.70 | 70.88 | 7.23 | 60.30 | 75.38 | 7.69 |
| 22 | 7/8 | 2-3/4 | 0.37 | 81.40 | 63.90 | 79.88 | 8.15 | - | - | - | - | - | - |
| 24 | 1 | 3 | 0.44 | 96.80 | 76.50 | 95.63 | 9.76 | 81.00 | 101.25 | 10.33 | 85.50 | 106.88 | 10.91 |
| 26 | 1-1/16 | 3-1/4 | 0.52 | 113.74 | 90.00 | 112.50 | 11.48 | - | - | - | - | - | - |
| 28 | 1-1/8 | 3-1/2 | 0.60 | 131.78 | 106.00 | 132.50 | 13.52 | 106.00 | 132.50 | 13.52 | 113.00 | 141.25 | 14.41 |
| 30 | 1-1/5 | 3-3/4 | 0.69 | 151.36 | 119.00 | 148.75 | 15.18 | 119.00 | 148.75 | 15.18 | 126.00 | 157.50 | 16.07 |
| 32 | 1-1/4 | 4 | 0.78 | 172.04 | 135.00 | 168.75 | 17.22 | 135.00 | 181.00 | 18.47 | 144.00 | 181.00 | 18.47 |
| 36 | 1-7/16 | 4-1/2 | 0.99 | 217.80 | 171.00 | 213.75 | 21.81 | 171.00 | 213.75 | 21.81 | 180.00 | 225.00 | 22.96 |
| 40 | 1-9/16 | 5 | 1.22 | 268.84 | 212.00 | 265.00 | 27.04 | 212.00 | 260.00 | 26.53 | 225.00 | 260.00 | 26.53 |
| 44 | 1-3/4 | 5-1/4 | 1.48 | 325.16 | 252.00 | 315.00 | 32.14 | 252.00 | 315.00 | 32.14 | 270.00 | 337.50 | 34.44 |
| 48 | 1-7/8 | 6 | 1.76 | 386.98 | 302.00 | 377.50 | 38.52 | 302.00 | 377.50 | 38.52 | 320.00 | 400.00 | 40.82 |
| 52 | 2-1/16 | 6-1/2 | 2.07 | 454.30 | 338.00 | 422.50 | 43.11 | 360.00 | 450.00 | 45.92 | 383.00 | 478.75 | 48.85 |
| 56 | 2-1/4 | 7 | 2.40 | 526.90 | 383.00 | 478.75 | 48.85 | 405.00 | 506.25 | 51.66 | 428.00 | 535.00 | 54.89 |
| 60 | 2-3/8 | 7-1/2 | 2.75 | 604.78 | 450.00 | 562.50 | 57.40 | 450.00 | 562.50 | 57.40 | 477.00 | 596.25 | 60.84 |
| 64 | 2-1/2 | 8 | 3.13 | 688.16 | 504.00 | 630.00 | 64.29 | 504.00 | 630.00 | 64.29 | 540.00 | 675.00 | 68.88 |
| 72 | 2-7/8 | 9 | 3.96 | 870.98 | 639.00 | 798.75 | 81.51 | 639.00 | 798.75 | 81.51 | 675.00 | 843.75 | 86.10 |
| 80 | 3-5/32 | 10-1/2 | 4.89 | 1075.14 | 765.00 | 956.25 | 97.58 | 810.00 | 1012.50 | 103.32 | 855.00 | 1068.75 | 109.06 |
| 88 | 3-7/16 | 11 | 5.91 | 1301.08 | 954.00 | 1192.50 | 121.68 | 954.00 | 1192.50 | 121.66 | 1008.00 | 1260.00 | 128.57 |
| 96 | 3-13/16 | 12 | 7.04 | 1548.36 | 1125.00 | 1406.25 | 143.49 | 1120.00 | 1400.00 | 142.86 | 1188.00 | 1485.00 | 151.53 |
| 104 | 4-1/8 | 13 | 8.26 | 1817.20 | 1260.00 | 1575.00 | 160.71 | 1350.00 | 1687.00 | 172.19 | 1440.00 | 1800.00 | 183.67 |
| 112 | 4-7/16 | 14 | 9.58 | 2170.60 | 1440.00 | 1800.00 | 183.67 | 1530.00 | 1912.50 | 195.15 | 1620.00 | 2025.00 | 206.63 |
| 120 | 4-3/4 | 15 | 11 | 2419.12 | 1710.00 | 2137.00 | 218.11 | 1710.00 | 2137.50 | 218.11 | 1800.00 | 2250.00 | 229.59 |
| 128 | 5-1/5 | 16 | 12.51 | 2752.42 | 1908.00 | 2385.00 | 243.37 | 2016.00 | 2520.00 | 257.44 | 2124.00 | 2655.00 | 270.92 |
| 136 | 5-2/5 | 17 | 14.12 | 3107.28 | 2124.00 | 2655.00 | 270.92 | 2250.00 | 2812.00 | 286.99 | 2385.00 | 2981.25 | 304.21 |
| 144 | 5-4/5 | 18 | 15.84 | 3483.70 | 2385.00 | 2981.25 | 304.21 | 2520.00 | 3150.00 | 321.43 | 2700.00 | 3375.00 | 344.39 |
| 160 | 6-2/5 | 20 | 19.55 | 4301.00 | 3015.00 | 2768.75 | 384.57 | 3015.00 | 3768.75 | 384.57 | 3195.00 | 3993.75 | 407.53 |
